Master Lock 1630 vs. 1652: Lift-Handle or Single-Point-Latch Locker?

Short answer: choose the Master Lock 1630 for a compatible right-hinged standard lift-handle locker and the Master Lock 1652 for a compatible right-hinged single-point horizontal-latch locker. Both are built-in combination locks with automatic locking, but their rear mechanisms engage different locker hardware. Similar dials do not make them interchangeable.

Master Lock 1630 vs. 1652 Comparison

Start With the Locker Hardware, Not the Dial

The visible faces of institutional built-in locks can look similar. The decisive part is behind the door: the lock must move and secure the locker’s actual handle or latch. Identify the locker with the door open, photograph the rear mechanism without exposing sensitive records, and confirm hinge side while facing the closed door. Hinges on the right indicate a right-hand opening.

The replacement locker-lock identification guide provides a broader survey workflow. This comparison applies only after the choice has narrowed to these two right-hand automatic-locking models.

Choose the 1630 for a Standard Lift-Handle Locker

The Master Lock 1630 is documented for standard lift-handle lockers with hinges on the right. Master Lock’s terminology guide describes the lift-latch action as a vertical-travel bolt engaging the lift-handle mechanism. The model locks automatically, uses a three-number combination, and provides five preset combinations with end-user registration and control charts.

A 1630 should not be selected merely because the locker has a recessed handle. Confirm that lifting the handle operates the mechanism shown for the 1630 application. If the school is comparing automatic lift-handle operation with a manual deadbolt, the separate 1630 vs. 1670 guide owns that decision.

Choose the 1652 for a Single-Point Horizontal Latch

The Master Lock 1652 is designed for standard single-point horizontal-latch lockers with hinges on the right. Its springbolt provides automatic locking. Master Lock also documents a button-less combination-change process that authorized staff can perform from outside the locker with the correct control key and system records.

The 1652 is not the general answer for every single-point locker. A rotating Wrap-Around-Latch™ application belongs to a different model family, and box or multiple-tier lockers use another mechanism. The existing 1652 vs. 1654 guide explains the horizontal-latch versus box-locker distinction.

What the Two Models Share

Both models are manufacturer-described built-in combination locks for indoor school, employee, and health-club use. Both have concealed mounting, a 1-7/8-inch body width, three-number operation, five preset combinations, control charts, and supervisory control-key functions. Both standard pages also identify extension hardware for documented thicker-door applications.

Those shared features do not override mechanism or handing. An extension kit does not correct the wrong latch type, and a right-hand lock should not be turned around as a substitute for a documented left-hand model.

Pre-Quote Verification Checklist

• Photograph the front and rear of a representative locker door.
• Confirm right-hand opening while facing the closed locker.
• Identify lift-handle movement or a single-point horizontal latch.
• Record the existing lock model and all suffixes exactly.
• Measure door thickness and note any existing extensions or spacers.
• State whether the new locks must join an existing registered system.

Frequently Asked Questions

Do the Master Lock 1630 and 1652 both lock automatically?

Yes, but through different mechanisms. The 1630 works with a lift-handle application, while the 1652 uses springbolt action for a single-point horizontal latch.

Can a 1630 replace a 1652?

Not as a default substitution. Their rear mechanisms are designed for different locker hardware, so compatibility must be verified.

Are both models for right-hinged doors?

The standard 1630 and 1652 product pages specify right-hinged lockers. Record the hinge side before ordering.

Can students choose their own combinations?

No. Master Lock documents five preset combinations administered through the registered system; authorized staff should follow the exact manufacturer procedure.

Get Help Identifying the Mechanism

For product-selection or quote help, contact School Lock Supply with non-sensitive front-and-rear photos, hinge side, door thickness, model markings, and quantities.

Master Lock references: 1630 specifications, 1652 specifications, locker installation and maintenance.
